Lug Bolt to Wheel Stud Conversion Kit, Dart/Renegade/Cherokee/500L/200

Review star icon

Read or Write Review

Model Number: 226721-STUD-KIT

We now carry a Lug Bolt to Wheel Stud Conversion Kit for the 2013-16 Dodge Dart 2015+Renegade/2014+Cherokee/2014+ 500L/2015-2016 Chrysler 200

You may be asking yourself, why would I need a wheel stud conversion kit?

This kit serves three purposes:

For those of you that want more options as far as colors and brands of lug nuts.

For those of you that are not fans of lug bolts, this allows you to get rid of the lug bolts

This kit allows you to more easily get different width wheel spacers, and run wheel spacers. When you have the factory lug bolts, for each different spacer you try out, you have to get different length lug bolts. Whereas with this kit, you can run up to 20mm thick spacers and use the same lug bolts.

Features of these bolts:

These bolts have a allen key head to allow you to quickly thread them into the hub, and a large barb to stop the stud from being tightened in too far.

These bolts are made with a cold forged tehnology for highest strength.

These bolts are made in Europe, and are a Class 10.9 bolt which is a very high strength. These are not studs made in a slave labor factory in China. This is a critical part of your car, and you dont want these breaking off in a corner, dont be cheap to save $30 and have your wheel break off.

These bolts are made in a factory that is ISO 9000 certified, which is a quality management standard.

These bolts are put through a 6 stage quality test, including 1) Hardness test, 2) Dimensional check, 3) Salt Spray test, 4) Tensile strength test, 5) Metallographic Analysis and 6) Torque and Tension test.

Keep in mind, in order to use this kit, you will need open ended lug nuts. You could use closed ended lug nuts if you were to cut down the stud excess length, but as they are now, they are too long and a closed ended lug nut would bottom out on the stud and not make contact with the wheel, thereby not securing the wheel. We offer open ended lug nuts that will work perfectly with this kit, sold seperately.

$89.99

Additional Options

Muteki Lug Nuts (for use w/ Wheel Stud Conversion), Dart / 500 / Renegade

Model Number: 226722

If you own a Dodge Dart/Jeep Renegade/Cherokee/500/500L and are planning to install the wheel stud conversion kit that Read more

Option

Lug Bolt to Wheel Stud Conversion Kit, Dart/Renegade/Cherokee/500L/200, Drivetrain: Store Name

Ask a Product Question

- *E-mail: (Required)
  *Name: (Required)

  Characters remaining: 500
  Our Q&A program is designed to educate our community.
  This is not to answer questions about your orders, or problems you are having with a part you ordered. If you have questions about a part you have already ordered, please contact us by email at info@modernperformance.com or call us 713-270-8520 for faster service.
Tim Plowey

What thread is the nut side of the stud?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  This stud uses a 12x1.25 thread pitch. You can source your own open ended 12x1.25 thread pitch nuts to use with these, or use the lug nuts that we offer with these.
Karina

What is the recommended torque whe installing these?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  The wheel stud conversion kit manufacturer states you should follow the OEM wheel lug torque specs. Chrysler says the Aluminum wheels should be torqued to 92 ft lbs, the steel wheels should be torqued to 89 ft lbs. So follow those specs.
Kody Rhoads

Will this work with the 2.4? And what does the ki all include?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  Yes, this kit fits all 2013-2016 Darts, like shown in the title of this kit. Doesn't matter what engine, transmission you have, this fits all Darts. Its a kit of 20 studs, as shown in the photos.
Scott

Can I get these for regular stock rims, no spacers?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  Yes, like we explained on the product page, these serve three purposes, and you dont have to need all three, you can just want one of these options.

  1) gives you more options for colors and brands of lug nuts
  2) allows you to get rid of the stock lug bolts and instead use a more standard lug nut system.
  3) allows you to use wheel spacers more easily.

  Yes, these work with any, and all types of wheels, whatever you have, if they fit on your Dart, these fit.
Corey Williams

Can i run an adapter on top of these lugs that is 1inch thickness in order to change the bolt pattern?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  Yes you could use the adapter, however you may have to cut down the studs as they may protrude past your adapter, and that would prevent you from bolting your wheel down.
Antonio Thomas

I wanna get these and Red Spiked Lug Nuts but the lugs are only 50 MM long without the spikes... would they be able to go on or would it not work?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  You can use whatever 12x1.25 thread pitch lug nuts. The worst case scenario, is if you use a longer lug nut like the spiked ones out there, then they could stick out further than you may expect. But that has nothing to do with the wheel stud conversion kit, that has to do with the length of your lug nuts of choice.
san

does the lug nuts need to be open?? and how much space we need to have normal lug nut with close end

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  Yes, the lug nuts need to be open, due to the studs being longer, and therefore closed lug nuts will not work as they will bottom out. Closed lug nuts just wont work, because they would have to be super long, and would look odd sticking out of the wheel so far.
Leelanau Auto

Will this work on a 2014 Jeep Cherokee?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  These fit:
  2013-2016 Dart
  2014-2020 Cherokee
  2014-2020 Fiat 500L
  2015-2020 Renegade
Larry Carnahan

do you have a kit that will work for a 2015 Chrysler 200 S AWD V6.
Lug Bolt to Wheel Stud Conversion Kit, Dart/Renegade/Cherokee/500L, i believe these are close to the 200.
TY

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  Yes this kit fits many Fiat/Chrysler vehicles.
  -Dodge Dart
  -Fiat 500L
  -Fiat 500X
  -Jeep Cherokee
  -Jeep Renegade
  -Ram Promaster City
  -Chrysler 200
Cameron Strand

Does the kit come with lug nuts

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  No, this kit is a set of 20 studs, as shown in the product photos. We offer Muteki lug nuts seperately, please check them out.
K.C.

Would these fit with running 2" spacers? And if so, with the extra 2" width of the spacers, would it still require open end lugs?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  We have not tested spacers with these, so we cannot say for sure, but we are fairly confident that these will not work with 2 inch spacers. Thats way too much. 1/2 an inch, maybe. 3/4 of an inch, possibly, but you need to test fit to be sure.
Walter Bedeski

Do you recommend using thread lock or is it good without it?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  You could use thread lock if you wanted, but its not required.
Scott Bogue

Does this part work for the 2017-2021 Jeep Compass as I do not see it on the compatibility list even though its very similar to the Jeep Renegade?

1 Answer
- E-mail: Name: (optional)

  Characters remaining: 500
  Type your response below:
- Customer Service Rep

  These studs work on many 2013- current Chrysler vehicles with m12-1.25 thread pitch. The only difference is that some of the vehicles have wheels with a larger bolt seat. So for bigger vehicles like the Cherokee/Compass you may try to find larger wheel nuts to use with these studs than the ones we carry.
